Shelly 1 PM UL

Control a wide range of home appliances and office equipment (lights, power lines, security systems, heating radiators, air conditioners, etc.) from anywhere with the smallest WiFi-operated relay switch with 16A UL Listed WiFi-operated relay switch with Power Management.

Please Login to See Pricing

Power supply AC 110-230V ?10%, 50/60H,z Power supply DC 12V, 30 – 50V, NO Dry contacts, Requires a neutral line, Has Power Management

Description

Specifications

Description

Specifications

POWER
Power supply AC	110-230V ±10%, 50/60Hz
Power supply DC	30 – 50V
SPECIAL FUNCTIONS
Dry contacts	No
Roller shutter mode	No
Device temperature protection	Yes
Overload protection	Yes
Power measurement	Yes
Working without a neutral line	No
FEATURES
Channels	1 Channel
Maximum load	16A
Operational temperature	0°C to + 40 °C
Device power consumption	< 1 W
Intelligent On/Off	Yes
Local and remote control	Yes
Sunrise/Sunset	Yes
Weekly Schedule	Yes
UL Listed option	Yes
CONNECTIVITY
Wireless	Yes
Wi-Fi Protocol	802.11 b/g/n
Wi-Fi Radio frequency	2412 – 2484 MHz
Wi-Fi Radio signal power	1mW
Wi-Fi Range	up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
DIMENSIONS
Size	41mm x 36mm x 17mm
